1 Phase ARD 5HP to 10HP

The Automatic Rescue Device (ARD) works on the principle of powering and operating the Elevator Controller at rated Voltage to perform the Rescue operation. The Rescue device interfaces with the VFD which has a unique feature of “Low voltage DC operation” to operate the Elevator Motor with Low voltage Battery.

The ARD comprises of Two-phase processor-based inverter. During Mains power ON, it monitors the power and continuously charges the Batteries. In the event of a power failure, the Rescue device will activate within the selectable “response time”. The Powerful Inverter will produce and supply 2-Phase,440V, sinusoidal power to the Controller. The Controller is now energized with 2-Phase power and will run the Motor in the nearest direction at low speed and bring the Elevator to the immediate next floor and opens the door automatically. Upon opening the doors, the trapped passengers shall exit and the Inverter will be off to prevent any further battery drain. When normal power resumes, the Automatic Rescue will automatically switch over the Controller to Normal Operation i.e. 3Phase Input.

This device is suitable for those buildings which don’t have an emergency power source allocated for the elevator. To fulfil the needs of customers and to make it fit for many applications, we offer various models of  Lift inverter: 1 Phase ARD 5HP to 10HP, ARD 7.5HP, ARD 10HP in Single Phase.
